2，6-二氨基庚二酸(2577-62-0)紅外圖譜(IR2)

產(chǎn)品名稱:2，6-二氨基庚二酸

CAS:2577-62-0

分子式:C7H14N2O4

分子量: 190.2

InChI:InChI=1/C7H14N2O4/c8-4(6(10)11)2-1-3-5(9)7(12)13/h4-5H,1-3,8-9H2,(H,10,11)(H,12,13)/t4-,5-/s3

InChIKey: GMKMEZVLHJARHF-GADJSHNENA-N

Smiles:C(O)(=O)[C@H](N)CCC[C@@H](N)C(O)=O |&1:3,8,r|

IR1

IR2

Mass

MS-NW-6926
DL-2,6-diaminoheptanedioic acid
C7H14N2O4           (Mass of molecular ion:    190)

   Source Temperature: 260 °C
   Sample Temperature: 230 °C
   Direct, 75 eV

      12.0       1.2
      15.0       4.3
      16.0       1.8
      17.0       3.0
      18.0       5.0
      26.0       4.2
      27.0      17.8
      28.0      57.4
      29.0      11.0
      30.0      20.9
      37.0       1.3
      38.0       2.9
      39.0      15.2
      40.0       4.5
      41.0      17.3
      42.0      21.7
      43.0      42.7
      44.0      16.8
      45.0       5.7
      46.0       4.8
      50.0       2.4
      51.0       3.3
      52.0       4.1
      53.0       5.5
      54.0      16.3
      55.0      19.8
      56.0     100.0
      57.0      16.2
      58.0       1.7
      65.0       1.9
      66.0       2.0
      67.0       6.8
      68.0      17.9
      69.0       9.7
      70.0      18.4
      71.0      10.4
      72.0      12.9
      73.0       2.4
      74.0       9.3
      75.0       2.4
      78.0       1.3
      79.0       2.0
      80.0       8.1
      81.0       6.0
      82.0      50.0
      83.0      39.7
      84.0      28.9
      85.0       2.9
      86.0       1.1
      93.0       1.6
      94.0       1.4
      95.0       1.1
      96.0       1.9
      97.0       6.8
      98.0       4.4
      99.0       4.0
     100.0       4.1
     101.0       1.0
     108.0       1.4
     109.0       8.3
     110.0       4.2
     111.0       4.2
     112.0       1.7
     115.0       2.0
     116.0       1.8
     123.0       1.6
     126.0      11.0
     127.0      13.7
     128.0      55.4
     129.0       8.9
     130.0       1.2
     143.0       2.9
     144.0       2.5
     145.0       3.6
     151.0       1.4
     152.0       1.0
     154.0      23.1
     155.0       3.2
     172.0       5.2
     173.0       1.5
     174.0       1.3

KBr disc
